Conveyor Belt Loader(Diesel) TY-XC80


TY-XC80 Conveyor Belt Loader(Diesel) is a special vehicle designed and manufactured by our company. It is specially used for loading and unloading luggage, light cargo and mail in and out of the bottom cabin of the aircraft

apply to:A300、 A310、 A318、 A319、 A320、 A330、 A340、 B707、 B727、 B737、 B747、 B757、 B767、 B777、 C919 、 DCB、 DC9、 1L-18、 1L-62、 MD11、 MD80,etc

Main Technical Parameter
Engine model :QSF2.8t3NA49 / C240-NBKEA-01-C2
Drive shaft model:2400000-HY430CT / HY430C / JSTY13014
Chassis models:XC80.01000000
Engine emission:National Ⅲ Emissions / National IV Emissions
Working range of conveyor belt (mm):1170-4330 (front) / 520-1540 (backend)
Wheelbase (mm):3000
Curb weight kg: 3450 / 3700
Channel circle outer diameter (mm): 20000
Overall dimensions (L × W × H) (mm): 8140×2100×1960
Transfer speed (m/s) : 0.16~0.5
Belt width (mm) : 700
Conveyor belt carrying capacity (kg/m) : 135
Additional Options : Available upon request

Jiangsu Tianyi Aviation Industy Co., Ltd.
Factory: No.2 Hang Kong Road High-tech zone, Jianhu county, Yancheng City, Jiangsu Province, P.R.China
Shanghai Office: Floor 6th, Bld 36, No.1218 Huateng Road, Qingpu District Shanghai, P.R.China
Tel: +86 21 5049 6088 / +86 400 9980 919
Mobile: +86 137 6133 5725 (As WeChat)
+86 189 6407 9542
E_ mail: joinsun@jstianyi.com.cn
Airport.GSE@jstianyi.com.cn
Website: www.tianyi-gse.com
