DIY Easy Operate Automatic Precision Dispensing Equipment for Cable


9DIY Easy Operate Automatic Precision Dispensing Equipment for Cable

Detail information
Y&D5200 is a new designed three axis dispenser robot with X/Y/Z axis,
Its workingrange of X/Y/Z axis is 200mm/150mm/50mm. This machine is
Made of the main robot, a motion control system, a dispenser controller, a
Teach pendant and some other accessories. It can be used in a wide range
Such as Automobile mechanical parts coating, cell phone buttons dispening,
Mobile phone battery packaging, laptop battery packaging, coil dispensing,
PCB bond fixed sealant, IC sealant, horn external punctuate glue, PDA sealant,
Etc. It is programming by the teach pendant which is easy to operate that user
Can learnt it in a few minutes. Once users make a program it can stored for next
Time use. The program dates are stored in the CF card ( it can store at least 100
Groups of programms, 4000 points/group )
This kind of dispensing robot arm is compact in size and economical in cost that can meet mang customers' requirements. Y&D5200 has powerful function which can be used online. With aluminium construction, it has shockproof function. You should know that no matter how heavy or hight your products are, it all can be used for they will be put on the plate but not put on the machine straightly.


Notice
All the quotations we offer to you are all without the plate's price. But if you need, we also can supply it to you, just need add the price into the quotation. On the other hand, the high of the tripod of the plate can be changed according to the hight of your products.


Specifications

Item Y&D5200

Item Y&D5200 Y&D5300
X/Y/Z working area (mm) 200/150/50 300/ 200/ 50
Load worktable 3.0kg
Speed PTP X&Y/Z (mm/sec) 0.1~500/350
Repeatability +/- 0.02mm / axis
Resolution 0.02mm/axis
Data memory 100 programs, 4000 points/program
Data storage CF card
Program Display Teach pendant LCD
Operation system PTP (point to point) & CP (continuous path)
Interpolation linear/circular 3 axis
Program method Teach pendant
I/O signals 8 inputs / 8 outputs
Power supply AC 90~260V 125W
Operating temperature 0~40° C
Motor system Micro stepping motor
Dimensions 485*380*475
Net Weight 23kg(without bottom plate )34kg (without bottom plate)
